| MODEL | Type | Unit Match or Number of Zones | Clg Cap MBtuH | SEER | Htg Cap MBtuH | HSPF | Refrigerant Connections | Dimensions HxWxD | Weight |
|---|---|---|---|---|---|---|---|---|---|
| MWM09Y1J | Indoor Wall | MRM09Y1J | 9.0 | 16.0 | 9.8 | 8.6 | 1/4-3/8 | 30x11x8 | 19 |
| MRM09Y1J | Outdoor | MWM09Y1J | 9.0 | 16.0 | 9.8 | 8.6 | 1/4-3/8 | 33.4x24.25x12.6 | 68 |
| MWM12Y1J | Indoor Wall | MRM12Y1J | 11.8 | 16.0 | 13.0 | 8.6 | 1/4-3/8 | 30x11x8 | 19 |
| MRM12Y1J | Outdoor | MWM12Y1J | 11.8 | 16.0 | 13.0 | 8.6 | 1/4-3/8 | 33.4x24.25x12.6 | 68 |
| MWM18Y3J | Indoor Wall | MRM18Y3J | 18.0 | 16.0 | 12.0 | 8.5 | 1/4-1/2 | 24x12x8 | 26 |
| MRM18Y3J | Outdoor | MWM18Y3J | 18.0 | 16.0 | 12.0 | 8.5 | 1/4-1/2 | 37.6x27.6x15.6 | 106 |
| MWM24Y3J | Indoor Wall | MRM24Y3J | 22.0 | 16.0 | 26.6 | 8.5 | 1/4-1/2 | 37.7x12.3x8 | 33 |
| MRM24Y3J | Outdoor | MWM24Y3J | 22.0 | 16.0 | 26.6 | 8.5 | 1/4-1/2 | 37.6x27.6x15.6 | 115 |
| MWM36Y3J | Indoor Wall | MRM36Y3J | 33.6 | 18.0 | 24.6 | 9.0 | 1/4-5/8 | 53x13x10 | 42 |
| MRM36Y3J | Outdoor | MWM36Y3J | 33.6 | 18.0 | 34.6 | 9.0 | 1/4-5/8 | 38.25x31x17 | 161 |
