| MODEL | Cooling Cap. MBtuH | SEER | Refrigerant Charge Oz. | Line Size | Dimensions HxWxD | Weight Lbs. |
|---|---|---|---|---|---|---|
| 4AC14L18P | 18.0 | 16.0 | 91 | 3/8-3/4 | 28.5x24.25x24.25 | 138 |
| 4AC14L24P | 23.0 | 16.0 | 92 | 3/8-3/4 | 28.5x28.25x28.25 | 146 |
| 4AC14L30P | 28.0 | 16.0 | 107 | 3/8-3/4 | 36.5x28.25x28.25 | 172 |
| 4AC14L36P | 34.0 | 16.0 | 107 | 3/8-7/8 | 36.5x28.25x28.25 | 177 |
| 4AC14L41P | 38.0 | 16.0 | 161 | 3/8-7/8 | 36.5x28.25x28.25 | 210 |
| 4AC14L42P | 40.0 | 14.5 | 138 | 3/8-7/8 | 28.25x28.25x28.25 | 208 |
| 4AC14L47P | 46.0 | 16.0 | 179 | 3/8-7/8 | 32.5x32.25x32.25 | 251 |
| 4AC14L48P | 46.5 | 12.5 | 174 | 3/8-7/8 | 32.5x28.25x28.25 | 220 |
| 4AC14L60P | 58.0 | 14.5 | 192 | 3/8-7/8 | 32.5x32.25x32.25 | 253 |
